This vertical section detail shows a storefront head condition intersecting a masonry wall assembly. The aluminum storefront framing member is anchored below brick masonry supported by horizontal flashing and weep mechanisms. Glazing is secured within the storefront framing profile using standard gaskets. The surrounding masonry veneer exhibits standard coursing and mortar joints.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
