A-8V6Y5 — Window - Jamb at Typ Branch Storefront

Architectural · A-8V6Y5

Window - Jamb at Typ Branch Storefront

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.51
Discipline: Architectural

Materials

Aluminum Brick Glass / Glazing Metal (misc.)Steel

Elements

Columns Entrances Facades / Cladding Insulation Storefronts Walls Windows

Text on the drawing

3X3 COLUMN PER STRUCTURAL SEALANT AND BACKER ROD STOREFRONT SYSTEM WITH BRAKE METAL ADAPTOR BRAKE METAL. MATCH SF COLOR 2" RIGID WALL INSULATION FINISH PER PLAN / SCHEDULE 16 3" = 1'-0" 17 WINDOW - JAMB AT ENTRY BRICK
