A double wall-mounted shelving assembly is constructed from 16 gauge stainless steel with an all-welded construction and a 4 inch depth. The shelves are supported by 14 gauge galvanized steel hat channel brackets secured to the wall using 1/4 inch - 20 stainless steel bolts with toggles or expansion shields appropriate for heavy loads. Each shelf hooks over the bend in the top of the bracket and includes a 20 gauge stainless steel liner with sealant applied at the wall and front edge. Matching risers are provided on the ends of shelves against walls or equipment, and brackets are spaced at a maximum distance of 24 inches on center.
REFER TO WRITTEN SPECIFICATIONS AND FOODSERVICE PLANS FOR FURTHER INFORMATION RICCA DESIGN STUDIOS FABRICATION SHALL COMPLY WITH NSF STANDARDS NSF PROVIDE MATCHING RISERS ON ENDS OF SHELVES AGAINST WALLS OR EQUIPMENT SECURE BRACKETS TO WALL WITH 1/4" (6mm) 20 GA. STAINLESS STEEL BOLTS ANCHORED WITH TOGGLES OR EXPANSION SHIELDS. APPROPRIATE FOR HEAVY LOADS 20 GA. STAINLESS STEEL LINER. SEAL AT WALL & FRONT EDGE 14 GA. GALVANIZED STEEL HAT CHANNEL BRACKETS HOOK SHELF OVER BEND IN TOP OF BRACKET 12 GAUGE STAINLESS STEEL HAT CHANNEL ISOMETRIC VIEW HAT CHANNEL BRACKET SECTION VIEW LOCATE BRACKET AT MAX. DISTANCE OF 24"(610mm) O.C. 4"(102mm) WIDE 16 GA. STAINLESS STEEL SHELF OF ALL WELDED CONSTRUCTION 4" (102 mm) 4" VERIFY MOUNTING HEIGHT WITH OWNER/OPERATER 4' - 10" (1473 mm) VERIFY MOUNTING HEIGHT WITH OWNER/OPERATER 5' - 10" (1778 mm) (356 mm) 1' - 2" DOUBLE WALL SHELF WITH CONCEALED BRACKETS FSD12-6 (102 mm)
