Architectural · A-8T2F4

Typical Stair at Landing

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Concrete Steel

Elements

Floors / Slabs Stairs

Text on the drawing

11" 1" 7" MAX. SEE STAIR SECTION CONCRETE FILLED STEEL PAN TREADS STEEL STRINGER CONCRETE LANDING LANDING FRAMING

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
