A single-ply membrane roofing system terminates at the parapet wall with a membrane flashing secured over a compatible substrate. The membrane seams are joined using a hot-air weld. The roof deck aligns directly beneath the roofing membrane system at the top of the wall assembly.
LINE OF ROOF DECK SINGLE-PLY MEMBRANE ROOFING SYSTEM HOT-AIR WELD MEMBRANE FLASHING LINE OF PARAPET / WALL SUBSTRATE COMPATIBLE WITH ROOFING SYSTEM
