A full-height partition as scheduled abuts a wall assembly finished with two layers of five-eighths-inch exterior grade gypsum board on each side. The ceiling suspension system features spring and neoprene vibration isolation hangers supporting four inches of batt insulation above the ceiling plane. A mechanical slot diffuser is integrated into the ceiling system spaced six inches typical from the partition junction, with manufacturer-specified trim completing the transition. Detail references direct coordination with the reflected ceiling plan and related sections.
PARTITION AS SCHEDULED MECH SLOT DIFFUSER 0' - 6" TYP. SEE RCP SEE SECTION TRIM PER MANUFACTURER ? 4" BATT INSULATION 2 LAYERS OF 5/8" EXTERIOR GRADE GYP BOARD SPRING+NEOPRENE VIBRATION ISOLATION HANGERS
