This concrete curb and gutter assembly features a profiled curb with tooled one-half inch radius edges and a three-eighths inch lip at the gutter transition. One-inch diameter schedule forty polyvinyl chloride weep holes are spaced at eight feet on center, sloped downward at a minimum of one inch from the back of the curb toward a rock pit. The assembly rests on natural grade with designated finish grade heights for sod and ground cover behind the curb. Expansion joints of one-half inch width are provided at sixteen feet on center maximum and at curve tangents and corners.
