A sixteen-gauge hollow metal door frame assembly is secured to a gypsum board partition with eighteen-gauge steel Z-clips. The partition is constructed with single twenty-two-gauge steel studs at the jambs and a single steel twenty-two-gauge track at the head, with a twelve-gauge channel required for head tracks over forty-two inches in length. The assembly is faced with five-eighths-inch gypsum board on each side. The Z-clips are welded to the frame and spaced at a minimum of two per head and three per jamb, and the frame is factory primed for field painting.
ASSEMBLY AND FIRE RATING INFO. SEE PARTITION TYPES FOR SINGLE 22 GA. STEEL STUD AT JAMBS AND SINGLE STEEL 22 GA. TRACK AT HEAD. (12 GA. CHANNEL FOR HEAD TRACK OVER 42" IN LENGTH) 16 GA. HOLLOW METAL DOOR FRAME ASSEMBLY W/ 18 GA. STEEL 'Z' CLIPS: 2 PER HEAD MIN. AND 3 PER JAMB MIN;WELDED TO FRAME, PRIMED FOR FIELD PAINTING 1/2" 2" 1/2" 5/8" GYP. BOARD
