Architectural · A-8N55W

Section View / Plan View

Units: imperial
Sheet: RA-M5.0.2
Discipline: Architectural

Elements

Floors / Slabs Insulation Walls

Text on the drawing

8" MIN FLOOR ABOVE WALL 1" ACOUSTIC LINER WALL 1" ACOUSTIC LINER PLAN VIEW SECTION VIEW

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
