A structural steel column is enclosed by steel studs on four sides with a half-inch clearance gap maintained at the partition intersections. Each steel stud framing layer is faced with half-inch gypsum board finished with tape and joint compound. The central steel column is protected with spray-applied fireproofing.
1/2" 1/2" GYP. STUD GYP. 09 2216 STEEL STUD TAPE & JOINT COMPOUND GYPSUM BOARD SPRAY-APPLIED FIREPROOFING STEEL STUD STEEL COLUMN, S.S.D. FULLY RECESSED FEC
