An .040-inch thick Acrovyn sheet is field cut to fit and applied over five-eighths-inch gypsum board on light gauge metal framing. The corner features an overlap joint between the intersecting wall protection panels.
OVERLAP JOINT .040 ACROVYN SHEET FIELD CUT TO FIT LIGHT GAUGE METAL FRAMING (TYP.) 5/8" GYPSUM BOARD (TYP.)
