A three-sixteenth-inch aluminum plate connects to an aluminum plate attachment system with a one-half-inch joint width. Interior finishes and structural backing layers interface directly with the framing and attachment components.
3/16" ALUM PLATE, SEE FOR ADDITIONAL NOTES ALUM PLATE ATTACHMENT SYSTEM 1/2" FO AL PL DIM PT INT FINISH, SID
