A one-half inch thick marble threshold is centered on the door centerline and set in an adhesive thin set bed over the substrate. The toilet room side features ceramic or porcelain tile abutting the threshold with a plus-or-minus one-half inch dimension. The adjacent room floor finish feathers up to a bevel at the opposite edge of the threshold. Dimensions indicate a one-half inch inset on one side, a one and three-quarter inch center dimension, and a total width of two and three-quarter inches.
1/2" 1 3/4" MARBLE THRESHOLD CENTERLINE DOOR & THRESHOLD FLOOR FINISH FEATHER UP TO BEVEL TOILET ROOM CERAMIC OR PORCELAIN TILE 2 3/4" +/- 1/2" ADHESIVE THIN SET BED
