This detail outlines a standard soil profile for landscape and garden areas featuring a top layer of mulch ranging from four to six inches thick over planting soil mix. The planting soil mix is installed in four to six inch lifts typically, referenced to project specifications for gardens or lawn mix. The subgrade is scarified to a minimum four inch depth below the soil layers, with overall depths varying depending on lawn or planting area requirements.
VARIES DEPEDING ON LAWN OR P.A. 4"-6" MULCH, REF SPECIFICATIONS SOIL MIX: PLANTING SOIL FOR GARDENS OR LAWN MIX, REF SPECS. INSTALL IN 4-6" LIFTS, TYP. SCARIFY SUBGRADE TO MIN. 4" DEPTH 0' - 3"
