A hollow structural section screen frame connects to structural steel framing at a top of steel elevation of 57'-0 3/8". The assembly is secured using a three-bolt connection on a gusset plate and four connection bolts through a three-eighths-inch thick plate. Fillet welds of one-quarter inch and five-sixteenths inch sizes are specified throughout the joint. A centerline of screen work point is established with four-at-twelve spacing dimensions.
TOP OF STEEL 57' - 0 3/8" CL OF SCREEN CONN BOLT (TOTAL OF 4) 3/8" PL 1/4 (5/16) 4@12 2" 2" WP 1 1/2" 4" (5/16) 1" TYP 1" 1 1/2" 3" 3"
