Bar grate treads with diamond plate nosings and risers span between structural steel stringers, featuring a two-inch wide color-contrasting non-slip strip at all treads and the upper approach. A one-and-one-quarter-inch diameter steel pipe post is welded to the steel channel and stringer at a maximum of five feet on center. The steel stringer supports the landing assembly and connects to the structural framing per structural drawings.
BAR GRATE TREADS W/ DIAMOND PLATE NOSING AND RISERS - typical 2" WIDE COLOR CONTRASTING NON-SLIP STRIP AT ALL TREADS AND UPPER APPROACH, typical STEEL STRINGER - REFER TO STRUCTURAL DRAWINGS - typical 1 1/4" Ø STEEL PIPE POST @ 5'-0" O.C. MAX. WELD TO STEEL CHANNEL AND STRINGER - typical 2" <■
