A horizontal bracing connection at a wide flange member utilizes five-eighths inch thick plates welded with five-sixteenths inch fillet welds typically. The brace members connect with two seven-eighths inch diameter A325-N bolts spaced at two inches, three inches, and two inches. Top and bottom contractor options are provided in lieu of bolts where indicated.
