The shaft wall partition consists of a central C-H steel stud flanked by gypsum liner panels fitted into the stud profile. Face layers of five-eighths-inch Type X gypsum board are applied to both outer sides of the assembly to achieve the required fire rating. Cavity spaces within the partition profile accommodate standard framing alignments.
09 29 00.B01 TYPE X GYP BD 5/8" 09 21 16.23.B00 GYP LINER PANEL 09 21 16.23.E00 C-H STUD
