A one-inch thick glass panel is secured within an aluminum base shoe measuring two and one-half inches in height by six inches in width. The base shoe sits atop a concrete curb, featuring a one-inch interior return and a sloped exterior metal flashing with a half-inch hem at the drip edge. Sealant joints and backing materials are detailed at the interior and exterior interface with the curb.
6" 3 3/4" 07 92 A 06 12 CC 07 91 C 07 92 B 07 63 F SLOPE TOP 1/2" HEM GLASS 1" 2 1/2" EXTERIOR INTERIOR 1" RETURN 1/2" GRID
