An aluminum window system is installed adjacent to a concrete tilt-up wall panel, featuring a dark bronze break metal trim attached with polyurethane construction adhesive. A four-inch vertical break metal portion is painted to match the adjacent concrete tilt-up panel. Break metal seams are provided as required along the two-foot six-inch vertical run.
BREAK METAL - DARK BRONZE ATTACH W/ POLYURETHANE CONSTRUCTION ADHESIVE BREAK METAL SEAM - AS REQUIRED 2" 2" 2" ALUMINUM WINDOW SYSTEM - SEE WINDOW SCHEDULE CONCRETE TILT-UP PANEL EXTERIOR INTERIOR 2'-6" 4" PAINT 4" VERTICAL BREAK METAL PORTION TO MATCH ADJACENT CONCRETE TILT-UP PANEL BREAK METAL - DARK BRONZE ATTACH W/ POLYURETHANE CONSTRUCTION ADHESIVE
