This 60-minute fire-rated door head assembly features a hollow metal door frame set within cold-formed steel framing. A 3-5/8 inch metal stud is nested in a metal track above the door frame. The surrounding partition consists of five-eighths inch Type X gypsum board on each side over metal studs, with insulation included where required. A tight-fitting smoke and draft control assembly is integrated at the door.
3-5/8" METAL STUD NESTED IN METAL TRACK METAL TRACK 5/8" TYPE 'X' GYP. BD. EACH SIDE OVER METAL STUD. SEE STUD TABLE FOR SIZE AND SPACING INSULATION WHERE OCCURS DOOR FRAME PER SCHEDULE WITH 60 MIN. U.L. RATING DOOR PER SCHEDULE WITH TIGHT-FITTING SMOKE AND DRAFT CONTROL ASSEMBLY DOOR DIM. SEE SCHEDULE ROUGH OPENING 1/2"
