A field fabricated pipe flashing assembly details the penetration waterproofing over rigid insulation. A stainless steel clamping ring is installed per manufacturer instructions at the upper pipe penetration. Non-reinforced flashing integrates with a reinforced membrane secured by fasteners and fastening plates installed per manufacturer specifications. Sealant is applied at the membrane edges over the insulation assembly.
1 1/2" TO 2" 12" MAX. 1" MIN. (APPX.) 1/2" MIN. 1 1/2" MIN. STAINLESS STEEL CLAMPING RING INSTALL PER MANUFACTURER FASTENER AND FASTENING PLATE INSTALL PER MANUFACTURER NON-REINFORCED FLASHING REINF. MEMBRANE SEALANT RIGID INSULATION
