A-8B3VX — Conduit Through Wall Detail

Architectural · A-8B3VX

Conduit Through Wall Detail

Units: metric
Sheet: RA-T2.1.2
Discipline: Architectural

Materials

Elements

Roof / Floor Openings Walls

Text on the drawing

CABLE TRAY (REFER TO OVERHEAD WIRE CABLE TRAY DETAIL) BONDING CONDUCTOR (TYP.) INSULATED BONDING AND GROUNDING BUSHING (TYP.) SEAL SLEEVE PENETRATION (TYP.) CONDUIT WALL BONDING CONDUCTOR (TYP.)
