This column section details a square structural column enclosed by circular Temple White granite stone cladding. The assembly features a three-eighths inch joint between stone segments filled with backer rod and sealant. Grid lines H.6 and G.3 establish the horizontal centerlines with corresponding dimensions of four and five-eighths inches and one foot one and seven-eighths inches.
H.6 G.3 1'-1 7/8" 1'-1 7/8" 2'-3 3/4" 4 5/8" 4 5/8" STONE CLADDING STRUCTURAL COLUMN, RE: STRUCTURAL DRAWINGS 3/8" JOINT. FILL WITH BACKER ROD & SEALANT. GRANITE, TEMPLE WHITE
