Base cabinets or equipment and upper cabinets or equipment are mounted to twenty gauge cold-formed metal studs using Type B mounting hardware. A furrdown or fascia panel drops from the ceiling to the upper cabinet. Vertical stud flanges remain uncut per structural notes, and additional mounting details are referenced on sheet A3.03.
BASE CABINET OR EQUIPMENT UPPER CABINET OR EQUIPMENT FURRDOWN OR FASCIA PANEL CEILING LINE OF STRUCTURE TYPE B MOUNTING TYPE B MOUNTING 20 GA METAL STUDS TYPE B MOUNTING NOTE: DO NOT CUT VERTICAL STUD FLANGES NOTE: REFER TO SHEET A3.03 FOR MOUNTING DETAILS
