A one and one-half inch diameter steel pipe handrail and one and one-half inch steel square metal railing mount to a metal plate or channel stringer. Cable railing is provided per shop drawings by others. The stair connection is bolted with a steel angle anchored to the concrete floor structure. Code compliance notes indicate sphere pass-through limits of six inches, four and three-eighths inches, and four inches for guardrail openings. Side rail height maintains a specified minimum above the finish floor.
1 1/2" DIA. PIPE HAND RAIL METAL PLATE OR CHANNEL STRINGER MIN. 1' - 0" METAL PAN STEEL TREADS OR CONC. FILLED STEEL PAN TREADS BOLT STAIR CONNECTION W/ STEEL ANGLE 6" DIA. SPHERE SHALL NOT PASS THROUGH 4 3/8" DIA. SPHERE SHALL NOT PASS THROUGH 1-1/2" STEEL SQUARE METAL RAILING - TYP U.N.O. CABLE RAILING - SHOP DRAWINGS BY OTHERS 4 " DIA. SPHERE SHALL NOT PASS THROUGH 3" 6'-0" 3/4" DIA. STEEL BAR FINISH FLOOR SIDE RAIL HEIGHT MINIMUM ABOVE FINISH FLOOR 1 1/2" = 1'-0" A411 C2 HANDRAIL DETAIL
