The assembly features a painted tube steel column supporting a painted tube steel beam at the top of the mechanical screen wall. A prefinished metal parapet cap sits over pressure-treated wood blocking and a continuous metal cleat. One-and-a-half-inch painted metal deck panels are installed horizontally along the exterior face of the tube steel column. All exposed exterior and interior structural steel is painted per specifications. A secondary tube steel beam is visible in the background beyond the column.
1‐1/2" METAL DECK PAINTED BOTH SIDES, INSTALLED HORIZONTALLY PAINTED T.S. COLUMN CONT. CLEAT PRESSURE TREATED WOOD BLOCKING PREFINISHED METAL PARAPET CAP 4" PAINTED TUBE STEEL BEAM, SEE STRUCTURAL TUBE STEEL COLUMN, SEE STRUCT. NOTE: PAINT ALL EXPOSED STEEL EXTERIOR INTERIOR B.O. METAL DECK PANELS 116'‐6" PAINTED TUBE STEEL BEAM, BEYOND, SEE
