An exterior horizontal joint detail features a three-sixteenths inch aluminum plate secured by an aluminum plate attachment system. The assembly includes interior finishes with dimensional clearances of nine and three-eighths inches, four inches, and three inches, totaling one foot four and three-eighths inches. The exterior side is indicated for proper orientation of the panel joints and mounting components.
EXTERIOR INT FINISH, SID FO AL PL DIM PT 3/16" ALUM PLATE, SEE FOR ADDITIONAL NOTES ALUM PLATE ATTACHMENT SYSTEM 1/2" 9 3/8" 4" 3" 1'-4 3/8"
