This emergency exit sign measures eight and one-half inches wide by six inches high overall, fabricated from three-eighths-inch-thick matte acrylic. The face features permanent raised text one inch high in Helvetica Neue 65 Medium font, accompanied by a graphic based on the sign location and a warning noting that an alarm will sound if the door is opened.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
