An aluminum louver screen with a finish matching the curtain wall connects to an aluminum structural silicone glazed curtain wall mullion. The assembly incorporates a scheduled vision glass insulated glass unit and maintains an aligned five-inch dimension relative to the edge of slab below.
DIM PT FOG EOS 1'-0" EOS BELOW ALIGN 5" 08 80 00.01 SCHD VISION GL IGU 08 44 13.11 ALUM SSG CW MULLION ALUM LOUVER FIN. TO MATCH CW
