Millwork assembly surrounds a door opening within a corridor partition. The door span measures four feet eight and three-eighths inches, with a note to verify this dimension in the field. The millwork surround has a typical depth of one foot four inches. Refer to detail seven and detail eight on sheet A800.2 for further construction information.
