The aluminum awning frame, specified as a Mapes Architectural Canopies Super Lumideck with integral drainage, is supported by an aluminum beam anchored to the exterior wall. The beam connection utilizes one-half inch diameter through-bolts with a backing plate, installed per the manufacturer's instructions. A tension rod extends from the outer edge of the awning frame back to the exterior wall assembly. The underside of the canopy is finished with an aluminum soffit. A downspout is integrated into the assembly, with its specific location determined by the project plans.
Text on the drawing
A-60013 06 8" HIGH PERFORMANCE COATING 1/2" THROUGHBOLTS WITH BACKING PLATE, INSTALL PER MFR. ALUMINUM BEAM, INSTALL PER MFR. ALUMINUM AWNING FRAME (BASIS OF DESIGN SUPER LUMIDECK BY MAPES ARCHITECTURAL CANOPIES, LLC, WITH INTEGRAL DRAIN) ALUMINUM SOFFIT EXTERIOR WALL E01 DOWNSPOUT, REFER TO PLAN FOR LOCATION(S) 4' - 2" A-60013 05
