This architectural detail shows a double-layer gypsum board wall assembly with sound attenuation insulation packed between metal studs. Resilient channels are fastened horizontally across the framing to decouple the gypsum board layers for sound transmission class rating improvement. An overall width dimension spans the complete assembly profile.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
