Vertical framing members in the pipe drop enclosure assembly for both wall bench and island bench conditions connect using Z-clips as detailed in the enlarged callout view. Height dimensions vary across the assembly to accommodate specific site conditions.
VARIES VARIES ENLARGED VIEW @ Z-CLIP ISOMETRIC @ WALL BENCH CONDITION ISOMETRIC @ ISLAND BENCH CONDITION
