A heavy-duty 15/16-inch T-rail runs perpendicular to wood planks, secured with direct screw connections through the grid into wood backers. Black fiber felt is installed above the wood planks as part of the ceiling module assembly.
WOOD BACKER BLACK FIBER FELT HEAVY DUTY 15/16" T-RAIL DIRECT SCREW CONNECTION THROUGH GRID TO WOOD BACKER WOOD BACKER BLACK FIBER FELT HEAVY DUTY 15/16" T-RAIL DIRECT SCREW CONNECTION THROUGH GRID TO WOOD BACKER
