A six-inch shotcrete wall bears on a concrete footing adjacent to the property line. A double layer of drainage mat is applied to the exterior face of the wall behind a two-inch clearance zone, paired with a crystalline waterstop installed at all vertical and horizontal construction joints. At the base, a four-inch PVC pipe weephole spaced at ten feet on center discharges into a six-inch drain tile surrounded by drain rock. An asphalt impregnated board separates the slab from the wall, and a perimeter seal is applied at all membrane penetrations.
F LEVEL P2 30.46' DOUBLE OF DRAINAGE MAT 2' - 0" PERIMETER SEAL TYP. @ MEMBRANE PENETRATION 4" PVC PIPE WEEPHOLES @10'-0". SEE MECHANICAL. CONCRETE FOOTING. REFER TO STRUCT. DWGS 6" DRAIN TILE. REFER TO MECH. DWGS. NOTE: PROVIDE DRAIN ROCK FOR 12" AROUND ALL DRAIN TILE AND FROM WEEP PIPES IN WALL TO DRAIN TILE. 6" SHOTCRETE WALL, SEE GEOTECH DWGS. PROPERTY LINE C1 F1 STAIR 01 P2-S01 SEE STRUCT. 4 1/2" 2" SEE FINISH SCHEDULE FOR WALL FINISHES CRYSTALLINE WATERSTOP AT ALL CONSTRUCTION JOINTS (BOTH VERTICAL AND HORIZONTAL) ASPHALT IMPREGNATED BAORD
