This wall top bracing detail features a continuous metal track secured to the partition framing with a twelve-gauge two-inch angle fastened using number ten sheet metal screws to both the track and the stud. Track backing is installed as specified by structural details. The wall surfaces are finished with five-eighths-inch gypsum board applied per plaster wall details. Ceiling systems and finishes are coordinated with reflected ceiling plans and interior elevations.
WALL PER PLAN WALL FINISH (WHERE OCCURS); REF. FINISH AND EQUIPMENT PLAN & INTERIOR ELEVATION 5/8" GYPSUM BOARD PER PLASTER WALL DETAIL 02/18.01 CONTINUOUS TRACK PER 09A/S0.92 12 GA. 2" ANGLE W/ #10 SMS TO BOTH TRACK AND STUD TRACK BACKING PER 11C/S0.92. CEILING SYSTEM, WHERE OCCURS SEE REFLECTED CEILING PLAN 6"
