This exterior soffit corner assembly features three-and-five-eighths-inch metal framing wrapped with a weather-resistant barrier and three-quarter-inch fire-treated plywood or approved non-combustible material. The exterior fascia utilizes Mitsubishi Alpolic AGT Grey aluminum composite material panels applied per manufacturer specifications. A flush reveal soffit system using Firestone Cityscape is installed at the underside, incorporating a perforated soffit vent with bug screen.
3/4" FIRE TREATED (FRTW) PLYWOOD OR APPROVED ALTERNATE NON-COMBUSTIBLE MATERIAL FLUSH REVEAL SOFFIT INSTALL FIRESTONE CITYSCAPE PER MANUFACTURES SPECS. 3 5/8" METAL FRAMING PERFORATED SOFFIT VENT W/ BUGSCREEN WEATHER RESISTANT BARRIER ACM FACIA PANEL Mitsubishi Alpolic - AGT Grey APPLIED PER MANUFACTURES SPECS.
