A ninety-degree curtain wall corner intersection features an FP-1 architectural fin. The assembly incorporates a dimension point set at three and one-quarter inches from the centerline, with variable fin lengths ranging from a three-and-three-eighth-inch minimum to a one-foot maximum. Typical clearances are maintained at one-quarter inch throughout the junction. Fin information refers to sheets A364 through A372.
DIM PT 3 1 / 4 " CURTAIN WALL FP-1 FIN 9 0 ° R E : A 3 6 4 - A 3 7 2 F O R F I N I N F O R M A T I O N L E N G T H V A R I E S 3 3 / 8 " ( M I N ) - 1 ' - 0 " ( M A X ) 1 3 / 3 2 " 1 1 1 / 1 6 " 1 3 / 3 2 " 2 1 / 2 " 1 / 4 " T Y P . V A R I E S 1 / 4 " T Y P . L E N G T H V A R I E S
