The light valance assembly at the tower curtain wall features a 1/4-inch press-braked aluminum plate bracket aligning with the curtain wall mullion. An FP-1 fin is positioned at a 59.04-degree angle relative to the tower curtain wall line, with plate cutouts accommodating the mounting geometry. Dimensions indicate a 2-1/2-inch centerline dimension for the fin, with 6-1/2-inch dimensions from the centerline of the fin to the inside face of the bracket on each side.
C L O F F I N T O I F B 6 1 / 2 " C L O F F I N T O I F B 6 1 / 2 " 5 9 . 0 4 ° 2 1 / 2 " LINE OF TOWER CW 1/4" PRESS BRAKED ALUMINUM PLATE BRACKET LINE OF LIGHT FIXTURE BELOW FP-1 FIN PLATE CUT OUTS LINE OF INSIDE FACE OF BRACKET( IFB) CW MULLION CL 6 1 / 2 " 9 1 / 2 "
