An aluminum storefront sill profile aligns with the rough opening and adjacent construction. One-inch insulating glass with dual edge sealing is secured using gaskets and sealant matching the aluminum or hollow metal frame and door unless noted otherwise. Mullion sizing is referenced in the project specifications. The exterior door opening dimensions coordinate with the door schedule.
EXTERIOR DOOR OPENING REFER TO SCHEDULE R.O. (ROUGH OPENING) INTERIOR ALIGN 1" INSULATING GLASS (GL-1) WITH DUAL EDGE SEALING RE:TO SCHEDULE FOR GLASS TYPE GASKET/ SEALANT - MATCH COLOR OF ALUMINUM OR H.M.FRAME/ DOOR U.N.O. GLAZING WINDOW/ CURTAIN WALL/ RE: SPECS FOR MULLION SIZE RE: SPECS FOR MULLION SIZE
