The assembly features an aluminum curtain wall mullion framing glazed units at a multi-faceted corner condition. Aluminum vertical fins project outward at thirty-degree angles, flanked by aluminum horizontal fins spanning three and a half inches and six and a half inches. Dimensions note a one foot four inch extension for the exterior fin layout.
90° 6 1/2" 1 1/4" 3" 1' - 4" 1' - 4" 30° 30° GLAZING UNIT GLAZING UNIT ALUM HORIZONTAL FIN ALUM HORIZONTAL FIN ALUM CURTAIN WALL MULLION ALUM VERTICAL FIN 3" ALUM VERTICAL FIN 3 1/2"
