The assembly transitions from a gypsum board wall to an acoustic tile ceiling using a shadow mold trim. Metal studs spaced at sixteen inches on center support the wall framing with a pro-x header fastened above. A diagonal metal stud brace tied with gusset plates provides in-plane lateral stability where gypsum board does not occur. Gypsum board with a corner bead finishes the vertical surface adjacent to the ceiling transition.
092216 BRACE 092216 MTL. STUD @ 16" O.C., SEE - 092900 GYP. BD. W/ CORNER BEAD 092216 PRO-X HEADER FASTENED TO 4" STUD ASSEMBLY ABOVE 095113 'SHADOW MOLD' TRIM, TYP. - -- WHERE GYP. BD. DOES NOT OCCUR, PROVIDE IN- PLANE BRACING ALIGN PER RCP 45°
