A tackboard is mounted to a partition per schedule using Z-clips installed per manufacturer requirements. The assembly incorporates type two backing as specified on related drawings. Trim is included where required per interior elevations. The partition construction and backing requirements are coordinated with finish schedules and interior elevation keys.
PARTITION PER SCHEDULE Z-CLIP PER MANUFACTURER'S REQUIREMENTS TYPE 2 BACKING; SEE TACKBOARD; SEE INT. ELEVATIONS AND FINISH SCHEDULE KEY; INSTAL PER MFR REQUIREMENTS 2/A9.20 TRIM WHERE OCCURS; SEE INTERIOR ELEVATIONS
