A-7FXRX — Probe and Tap Location Installation for Measured Medium

Mechanical · A-7FXRX

Probe and Tap Location Installation for Measured Medium

About this detail

Probe or tap installation positions vary by one hundred twenty degrees for air and gas applications and sixty degrees for liquid and steam applications around the pipe circumference. Each installation utilizes specific angular offsets of thirty degrees from the reference axes.

DEPENDING ON STATE OF MEASURED MEDIUM INSTALLATION OF PROBE OR TAP LOCATION LIQUID AND STEAM AIR AND GAS APPLICATIONS APPLICATIONS 120° 30° 60° 30°

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
