A Type 1 backing plate is secured with one-quarter inch TEKS screws spaced at twelve inches on center and at the ends. The assembly integrates with light-gauge steel studs and gypsum board construction.
TYPE 1 BACKING PLATE SECURE TO BACKING PLATE W/ 1/4" TEKS SCREWS @ 12" O.C. & ENDS
