The assembly consists of an upper cabinet door, a drawer, and a base cabinet with specified hardware positioning. Pull locations are dimensioned with equal spacing across the drawer and cabinet door faces. A lock cylinder is positioned two inches from the top edge of the drawer face and on the lower portion of the base cabinet door. Equal spacing dimensions govern the alignment of pulls and locks across the casework elevations.
EQ EQ EQ EQ UPPER CABINET DOOR DRAWER BASE CABINET CABINET PULL LOCATIONS 2” LOCK
