A concrete dock door opening incorporates a continuous horizontal V-reveal at the base of the 10-inch pour-through and rigid insulation. Vertical bevels surround all concrete openings, transitioning to meet the horizontal reveal that continues across the entire dock face. A 14-inch by 24-inch dock restraint embed plate sits at the base of each dock door, with exact placement coordinated on-site. All concrete edges at the pour-through opening and door perimeter require beveling.
Text on the drawing
BEVEL AROUND ALL OPENINGS IN CONCRETE DOCK DOOR 10" 10 A502 TYP 10 A502 TYP BEVEL AROUND POUR THROUGH OPENING 10" POUR THROUGH 4 A501 TYP CONTINUE VERTICAL BEVEL / REVEAL DOWN TO HORIZONTAL REVEAL CONTINUE REVEAL HORIZONTALLY THROUGHOUT ENTIRE DOCK CONTINUOUS HORIZONTAL V- REVEAL AT BOTTOM OF 10" DOCK POUR-THROUGH / RIGID INSULATION. 2'-0" 1'-2" DOCK RESTRAINT EMPED PLATE UNDER EACH DOCK DOOR - 14" X 24" COORDINATE PLACEMENT
