A cable tray carrying electrical cables penetrates through a concrete masonry unit wall partition. Mineral wool insulation is tightly packed into the wall opening around the cables and tray. Firestop sealant is applied at the cable tray and gypsum board interface on both sides of the wall in compliance with Underwriters Laboratories system number W-J-4059.
CABLE TRAY RE: ELEC TN101 THRU TN109 FIRESTOP SEALANT AT CABLE TRAY/ GYP BD INTERFACE ON BOTH SIDES OF WALL MINERAL WOOL INSULATION TIGHTLY- PACKED INTO OPENING ELEC CABLES RE: ELEC TN101 THRU TN109 EQUAL TO UL SYSTEM NUMBER W-J-4059 TYP CABLE TRAY PENETRATING CMU WALL DETAIL CMU WALL, RE: PARTITION TYPE
