A one-quarter-inch press-braked aluminum plate bracket attaches in relation to a curtain wall mullion and an FP-1 fin. The assembly includes plate cutouts and positions the light fixture centered on the plate at a fifty-nine point zero four degree angle. Dimensions detail the layout from the line of inside face of bracket to the centerline of the fin at six and one-half inches, with overall fin extension dimensions reaching two feet zero inches to the edge. The light fixture is positioned below with reference lines tracing the tower curtain wall.
O F G T O E D G E O F F I N 2 ' - 0 " C L O F F I N T O I F B 6 1 / 2 " C L O F F I N T O I F B 6 1 / 2 " 5 9 . 0 4 ° 1 " 1 1 1 / 2 " 1 / 2 " 1 0 5 / 8 " 1 / 2 " 2 3 / 8 " 1 / 4 " 2 3 / 4 " 1 / 8 " 2 1 / 2 " 1 / 8 " 2 3 / 4 " 1 / 4 " 2 3 / 8 " 1 ' - 1 1 / 2 " LINE OF TOWER CW 1/4" PRESS BRAKED ALUMINUM PLATE BRACKET LINE OF LIGHT FIXTURE BELOW FP-1 FIN PLATE CUT OUTS LINE OF INSIDE FACE OF BRACKET( IFB) CW MULLION CL L I G H T F I X T U R E C E N T E R E D O N P L A T E
